Standard Result
Size 1219mm x 178mm
Thickness 3mm
Wear layer 0.5mm
Warranty Commercial
Domestic
10 Years*
15 Years*
Bevelled edge No
Standards EN 649
ASTM F1700
Pass
Pass
Classification Commercial Heavy Duty use
Domestic Heavy Duty use
Reaction to fire AS ISO 9239.1:200 CRF: 9.4 kW/m²
Smoke value: 84% min.
Slip resistance AS/NZS 4586:2004 See separate table
Staining resistance EN 423
ASTM F925
Class 0
Pass
Light fastness ISO 105-B02
ASTM F1515
≥ 7
< 8
Abrasion resistance EN 660-2
ASTM D3884
Group T
Pass
Dimensional stability EN 434
ASTM F2199
≤ 0.25%
Pass
Acoustic impact
noise reduction
EN ISO 717-2
EN ISO 140-8
rLw= 4 db¹
Electrical behaviour
body voltage
EN 1815 Pass
Indentation - residual EN 433
ASTM F1914
≤ 0.1mm
<8%
Castor chair
continuous use
EN 425 Pass
Thermal conductivity ISO 8302 0.0147m²K/W
Suitable for underfloor
heating.
Light reflectance value BS 8493:2008+A1:2010 See website for LRV results
Adhesive General use:
High temperature:
Karndean Mega-Bond
Karndean 8000 2-part
Polyurethane
Recycling Suitable
*Subject to terms, please see our website. Full technical data is available on our website.
¹Result is Ln,w + C¹ = 57 dB when installed on Regupol 4515 acoustic underlay
Karndean Designflooring Australia
Call: 1800 331 170
Email: customerservice@karndean.com.au/karndean.com.au" target="_blank" title="Visit karndean.com.au">karndean.com.aucustomerservice@karndean.co.nzng New Zealand
Call: 0800 442 101
Email: customerservice@karndean.co.nz
www.karndean.com
Slip Resistance
Product Code Size (mm) Oil-wet
Ramp
Wet
Pendulum
VGW41T, VGW42T,
VGW44T, VGW49T,
VGW51T, VGW53T,
VGW54T, VGW70T,
VGW71T, VGW80T,
VGW81T, VGW83T
VGW84T, VGW86T,
VGW87T, VGW88T,
VGW89T
1219 x 178
R11 W
VG1-7, VG5-7,
VGW33T, VGW40T
R10 Y
7EN 14041 Manufactured to:
