Welding Positions Welding Positions

Head Office Sales: Tel: 01420 588180 Fax: 01420 588184 Email: sales@swp.uk.netttp://swp.uk.net" target="_blank" title="Visit swp.uk.net">swp.uk.netairsales@swp.uk.netpot Sales: Tel: 01942 719930 Fax: 01942 729937 Email: airsales@swp.uk.net

20Standards

Mechanical Properties

Cu

96.0

Si

3.00

Mn

1.00

AWS : A5.7 ER Cu Si - A

EN 24373 Cu 6560 (Cu Si 3 Mn 1)

BS 2901 C9

Melting Point ºC 980

UTS N/mm2 350

Hardness BHN 90

Features and Applications

• Ideal for fusion welding materials of similar composition eg

copper alloy (brass). Frequently used in artistic foundries

where good colour match is required, also TIG brazing ferrous

and dissimilar materials

• Artistic foundries, automotive industry, repair and maintenance

Current Type

DC-

Shielding Gas

Pure Argon

Chemical Composition

Product Information

5.0kg Tube

Diameter Part No.

1.6mm 7154

2.4mm 7155

3.2mm 7156

Approvals on request

Manufacturer's Approvals

Super6 C9

Standards

Mechanical Properties

Cu

99.5

Mn

0.25

Si

0.25

AWS : A5.7 ER Cu

EN 24373 Cu 1898 (Cu Sn1)

BS 2901 C7

Melting Point ºC 1025

UTS N/mm2 220

Hardness BHN 70

Features and Applications

• High quality rod containing a minimum of 98.5% copper with

deoxidizing elements suitable for joining oxygen free copper

and copper materials subject to high strain

• Copper boilers, brewing industry and power generation

Current Type

DC-

Shielding Gas

Pure Argon

Chemical Composition

Product Information

Approvals on request

Manufacturer's Approvals

5.0kg Tube

Diameter Part No.

1.6mm 7158

2.4mm 7159

3.2mm 7160

Super6 C7

Copper

TIG
