Head Office Sales: Tel: 01420 588180 Fax: 01420 588184 Email: sales@swp.uk.netttp://swp.uk.net" target="_blank" title="Visit swp.uk.net">swp.uk.netairsales@swp.uk.netpot Sales: Tel: 01942 719930 Fax: 01942 729937 Email: airsales@swp.uk.net 53Brazing

Standards

Mechanical Properties

P

6.00

Cu

92.0

Ag

2.00

AWS : B Cu P-6

EN 1044 : CP105

BS 1845 CP2

Melting Point ºC 650

UTS N/mm2 420

Hardness BHN 190

Features and Applications

• A copper phosphorous rod with 2% silver to give improved

ductility and easier flowing characteristics. It is also highly

resistant to corrosion. The rod is self fluxing on copper but a

copper flux is required on brass joints

• Electric motors, hot water cylinders, copper/brass fabrication

Product Information

Current Type

Recommended Gas

Oxygen/Acetylene

Chemical Composition

Welding Positions

1.0kg Tube

Diameter Part No.

2.4mm 7537

3.2mm 7538

Approvals on request

Manufacturer's Approvals

CP2

Standards

Mechanical Properties

P

6.00

Cu

89.0

Ag

5.00

AWS : B Cu P - 3

EN 1044 : CP 104

BS 1845 CP4

Melting Point ºC 640

UTS N/mm2 600

Hardness BHN 190

Features and Applications

• A copper phosphorous rod with 5% silver to give excellent

flow and ductility (greater than CP2). The rod is self-fluxing

on copper but a copper flux is required when joining brass

• General copper/brass fabrications

Product Information

Current Type

Recommended Gas

Oxygen/Acetylene

Chemical Composition

Welding Positions

1.0kg Tube

Diameter Part No.

1.6mm 7499

2.4mm 7500

Approvals on request

Manufacturer's Approvals

CP4
